Commercial Application
The commercial vehicle series battery products of SVOLT followed the form of standard box and synchronized with the innovative iteration of the short blade series cells.
Core Competitiveness
Sincerity, always accompanying every kilometer along the way; real intention, always guaranteeing the power to reach the distance.
-
Shared use of commercial and passenger vehicles
Based on the development of battery systems of passenger vehicles, a large number of verifications have been conducted to meet commercial application needs; with mature production line technology, each process has undergone large-scale inspection of passenger vehicle products.
Shared use of commercial and passenger vehicles
-
Simplify
The differences in configuration of different vehicle models were thoroughly analyzed to seek common while reserving differences, and build a universal standardized battery system that takes into account the design of quick change and charging schemes for heavy trucks to meet different application conditions.
Simplify
-
Fast speed
For fast charge/ultra-fast charge and energy replenishment of commercial vehicles in long-distance intercity transportation, SVOLT has launched a prismatic LFP battery that meets the average 3C ultra-fast charge to complete 80% energy replenishment in 20 minutes.
Fast speed
-
Temperature retention
Short blade cell has double-layer architecture, with optional temperature control unit layout and shorter conduction path to achieve better temperature uniformity, while meeting the rapid heat dissipation needs of special working conditions. The temperature difference inside the cell is less than 10 ℃.
Temperature retention
-
Shared use of commercial and passenger vehicles
Based on the development of battery systems of passenger vehicles, a large number of verifications have been conducted to meet commercial application needs; with mature production line technology, each process has undergone large-scale inspection of passenger vehicle products.
Shared use of commercial and passenger vehicles
-
Simplify
The differences in configuration of different vehicle models were thoroughly analyzed to seek common while reserving differences, and build a universal standardized battery system that takes into account the design of quick change and charging schemes for heavy trucks to meet different application conditions.
Simplify
-
Fast speed
For fast charge/ultra-fast charge and energy replenishment of commercial vehicles in long-distance intercity transportation, SVOLT has launched a prismatic LFP battery that meets the average 3C ultra-fast charge to complete 80% energy replenishment in 20 minutes.
Fast speed
-
Temperature retention
Short blade cell has double-layer architecture, with optional temperature control unit layout and shorter conduction path to achieve better temperature uniformity, while meeting the rapid heat dissipation needs of special working conditions. The temperature difference inside the cell is less than 10 ℃.
Temperature retention
Application Scenarios
-
HEAVY TRUCK
-
LIGHT TRUCK
Heavy trucks and construction machinery
Great power, progressive improvement
-
Highly safe
The standardized box structure use short blade cell, which does not ignite or smoke during penetration; the system with ultra-low center of gravity meets the vibration requirements of multiple national standards.
-
High energy
The dramatic increase in volumetric specific energy increases battery capacity by 15% for the same volume.
-
High economic efficiency
The number of subcomponents is reduced by approximately 15%, significantly reducing product costs.
-
High reliability
Over 500A overcurrent capacity and 20,000 cycles of mechanical connector lifespan.
Light trucks
Riding the waves by light trucks of SVOLT
-
High cycle times, long lifespan
Based on the optimization of passenger vehicle cell solutions and matching with commercial needs, the cycle life of cell exceeds 4,000 weeks.
-
High capacity
With reference to standardized boxes of heavy trucks, high capacity, high safety, high reliability, and high economic efficiency are achieved, with 100kWh of electricity, to meet daily commercial transportation needs.
-
Reserve upgrade
A high-rate fast charge system solution is reserved for subsequent iteration upgrades.
Solution Products
-
230Ah
-
160Ah
-
147Ah
-
106Ah
-
230Ah
The classic square form is followed, with standardized low-power single pack that can be used for construction machinery, buses, light and heavy trucks, with strong compatibility.
Single energy density reaches 175Wh/kg, which is safe and reliable with mature technology.
-
160Ah
L600 prismatic cell for compatible applications of light/heavy trucks.
Standardized double-layer long box structure with high integration and efficient thermal management performance.
Single energy density ≥ 185Wh/kg.
-
147Ah
L600 prismatic fast charge LFP cell with 2.2C fast charge capability.
Double layered architecture and multi-layer cooling to ensure efficient operation of the system.
-
106Ah-L600 Short blade cell
Shared use of commercial and passenger vehicles, achieving compatibility of chassis space of low vehicles.
Single cell energy density ≥ 185Wh/kg.
They are Using Products from SVOLT
Perfect replacement of fuel forklifts and accelerated replacement of lead-acid forklifts.
Vehicle-grade high-performance battery is selected, which can restore to 90% of its capacity in one hour and can continue to charge quickly and operate continuously in hot weather, providing more reliable safety protection.
Assisting in realizing all imaginations about intelligent transportation capacity by clean energy in the future.
Providing solutions for the long cycle and fast charge of a new generation of prismatic cell for commercial vehicle battery system, with the complete vehicle as the core, and a comprehensive layout of new energy and intelligence.
Assisting Great Wall Heavy Industry in searching for new business opportunities in "an intensely competitive market".
Supplying standard C-box products, developing specialized T-boxes for construction machinery with high structural strength to adapt to harsh working conditions, and promoting green transformation in the field of construction machinery.
Creating an ultimate safe and stable new energy-driven heavy truck.
Providing various battery standard products for heavy trucks, including 210KWh, 282KWh, 350KWh, etc., covering various solutions such as battery switching and fast charge, to assist in green transportation.
Exploring a new journey of more comfortable travel: Providing mature coach G-box products for the new V series of Haige, which is safe and stable with long range and fire extinguishing devices.
Safe and stable mature coach G-box product with long range and fire extinguishing device.
